PHASED ARRAY

What we have to offer with this technology:

  • Ultrasonic testing using specialized multi element “array” transducers, used for a large variety of inspection and measurement applications

  • Can detect flaws not easily found with conventional NDT like RT and manual UT

  • Information displayed in multiple formats, i.e. A, B, C, & D scans. Data captured and stored for subsequent access

  • Can be utilized anywhere traditional ultrasonic testing is applied



Consistent inspections that encompass proper procedures,
correct techniques, calibration and data evaluation
are all factors that allow for development and implementation

of an assessment program to be effective.



MISSION:

To serve our customers by utilizing information and technology,
that provide real-time answers, to increasingly complex failure/corrosion issues.
